36V Lithium battery charger
36V lithium battery generally refers to 10 lithium-ion battery packs in series (nominal voltage 36V or 37V) or 12 lithium iron phosphate battery packs in series (nominal voltage 38.4V), and the battery capacity is mainly between 2Ah and 200Ah.
36V lithium batteries have a wide range of application scenarios, common application scenarios include: electric wheelchairs, electric scooters, electric bicycles, home energy storage, outdoor emergency power supply, solar energy storage, high-power power tools, mobile industrial equipment, robots, etc.
Green Digital Power has more than 20 years of professional R&D and manufacturing experience in the field of battery chargers and battery management. For various 36V lithium battery packs with different rated voltages and different battery capacities, we recommend the following standard models of smart chargers for you to choose from:
42V 1.8A Lithium Ion charger (G100-36L) 43.2V 1.8A LiFePO4 charger (G100-36F) | ||
| Input feature | AC 100~240V 50~60Hz 1.5A |
Output feature & suit battery | G100-36L: 42V 1.8A, suit 10s Li-ion 2~18Ah G100-36F, 43.2V 1.8A, suit 12s LiFePO4 2~18Ah | |
Power efficiency | 84% | |
Charge Curve | pre-charge + C.C. charge + C.V. charge + cut-off | |
Charge Display | Four LEDs to indicate battery SOC (capacity level) | |
Size & Weight | 175 x 72 x 40mm/400g | |
Protections | OCP, OVP, short circuit, battery reversed | |
Safety & EMC | CCC, CE, cTUVus, FCC, PSE | |
Housing & cooling | ABS+PC plastic housing, natural cooling (without fan) | |
Input & output type | AC inlet ICE-320-C8 type;DC type: 5.5*2.5*12mm barrel plug | |
View more details, click here to download specification, G100-EN.pdf | ||
42V 2A Lithium Ion charger (GaN085-420020) 43.2V 1.9A LiFePO4 charger (GaN085-432019) | ||
| Input feature | AC 100~240V 50~60Hz 1.5A |
Output feature & suit battery | GaN085-420020: 42V 2A, suit 10s Li-ion 2~20Ah GaN085-432019, 43.2V 1.9A, suit 12s LiFePO4 2~20Ah | |
Power efficiency | 92% (GaN solution, compact size) | |
Charge Curve | pre-charge + C.C. charge + C.V. charge + cut-off | |
Charge Display | Four LEDs to indicate battery SOC (capacity level) | |
Size & Weight | 114 x 68 x 29mm/350g | |
Protections | OCP, OVP, short circuit, battery reversed | |
Safety & EMC | CE, FCC | |
Housing & cooling | ABS+PC plastic housing, natural cooling (without fan) | |
Input & output type | AC inlet ICE-320-C8 type;; DC type: 5.5*2.5*12mm barrel plug | |
View more details, click here to download specification, GAN085-4LED-EN.pdf | ||
42V 4A Lithium Ion charger (G168-420040) 43.2V 3.8A LiFePO4 charger (G168-432019) | ||
| Input feature | AC 100~240V 50~60Hz 2.0A, PF>0.95 |
Output feature & suit battery | G168-420040: 42V 4A, suit 10s Li-ion 4~40Ah G168-432038, 43.2V 3.8A, suit 12s LiFePO4 4~40Ah | |
Power efficiency | 92% | |
Charge Curve | pre-charge + C.C. charge + C.V. charge + cut-off | |
Charge Display | Bi-color LED, RED charging, GREEN full/idle | |
Size & Weight | 175 x 72 x 40mm/700g | |
Protections | OCP, OVP, short circuit, battery reversed | |
Safety & EMC | cTUVus, CCC, TUV, CE, CB, RCM, PSE, FCC, KC | |
Housing & cooling | ABS+PC plastic housing, natural cooling (without fan) | |
Input & output type | AC inlet ICE-320-C8 type; DC type: 5.5*2.5*12mm barrel plug | |
View more details, click here to download specification, G168-CH-EN.pdf | ||
42V 7A Lithium Ion charger (G300-420070) 43.2V 6.9A LiFePO4 charger (G300-432069) | ||
| Input feature | AC 100~240V 50~60Hz 3.5A, PF>0.95 |
Output feature & suit battery | G300-420070: 42V 7A, suit 10s Li-ion 7~70Ah G300-432069, 43.2V 6.9A, suit 12s LiFePO4 7~70Ah | |
Power efficiency | 92% | |
Charge Curve | pre-charge + C.C. charge + C.V. charge + cut-off | |
Charge Display | Bi-color LED, RED charging, GREEN full/idle | |
Size & Weight | 220 x 105 x 43mm/1300g | |
Protections | OCP, OVP, short circuit, battery reversed | |
Safety & EMC | cTUVus, CCC, TUV, CE, CB, RCM, PSE, FCC, KC | |
Housing & cooling | ABS+PC plastic housing, natural cooling (without fan) | |
Input & output type | AC inlet ICE-320-C14 type; DC type: SB-50/XT-60 | |
View more details, click here to download specification, G300-CH-EN.pdf | ||
42V 15A Lithium Ion charger (G600-420142) 43.2V 14A LiFePO4 charger (G600-432138) | ||
| Input feature | AC 100~240V 50~60Hz 7A, PF>0.95 |
Output feature & suit battery | G600-420142: 42V 14.2A, suit 10s Li-ion 15~150Ah G600-432138, 43.2V 13.8A, suit 12s LiFePO4 14~140Ah | |
Power efficiency | 92% | |
Charge Curve | pre-charge + C.C. charge + C.V. charge + cut-off | |
Charge Display | LCD digital display show voltage, current, capacity, SOC, SOH and run time | |
Size & Weight | 240x 117 x 66mm/1500g | |
Protections | OCP, OVPOTP, short circuit, battery reversed | |
Safety & EMC | CB, cTUVus, CE, FCC | |
Housing & cooling | Aluminum Alloy housing, FAN cooling, | |
Input & output type | AC inlet ICE-320-C14 type; DC type: XT-60 | |
Communication port: CAN (More details, click here to download specification, ( G600-EN.pdf) | ||
42V 18A Lithium Ion charger (WP800-420180) 43.2V 18A LiFePO4 charger (WP800-432180) | ||
| Input feature | AC 100~240V 50~60Hz 8A, PF>0.95 |
Output feature & suit battery | WP800-420180: 42V 18A, suit 10s Li-ion 20~200Ah WP800-432180,43.2V 18A, suit 12s LiFePO4 20~200Ah | |
Power efficiency | 92% | |
Charge Curve | pre-charge + C.C. charge + C.V. charge + cut-off | |
Charge Display | Three-color LED indicate charging status | |
Size & Weight | 288x 130 x 82mm/2500g | |
Protections | OCP, OVP, short circuit, battery reversed, waterproof | |
Safety & EMC | CE, FCC | |
Housing & cooling | Aluminum Alloy casting housing, FAN cooling, IP67 class | |
Input & output type | AC plug type: US, EU, PSE, CCC; DC type: XT-90 | |
Communication port: CAN (More details, click here to download specification,( WP800-EN.pdf ) | ||
42V 28A Lithium Ion charger (G1200-420280) 43.2V 28A LiFePO4 charger (G1200-432280) | ||
| Input feature | AC 100~240V 50~60Hz 13A, PF>0.95 |
Output feature & suit battery | G1200-420280: 42V 28A, suit 10s Li-ion 30~300Ah G1200-432280, 43.2V 28A, suit 12s LiFePO4 30~300Ah | |
Power efficiency | 92% | |
Charge Curve | pre-charge + C.C. charge + C.V. charge + cut-off | |
Charge Display | LCD digital display show voltage, current, capacity, SOC, SOH and run time | |
Size & Weight | 265x 134 x 60mm/2500g | |
Protections | OCP, OVP,OTP, short circuit, battery reversed | |
Safety & EMC | CB, cTUVus, CE, FCC | |
Housing & cooling | Aluminum Alloy casting housing, FAN cooling | |
Input & output type | AC inlet ICE-320-C14 type; DC type: SB-50 | |
Communication port: CAN (More details, click here to download specification, G600-EN.pdf ) | ||
42V 40A Lithium Ion charger (WP1800-420400) 43.2V 40A LiFePO4 charger (WP1800-432400) | ||
| Input feature | AC 100~240V 50~60Hz 16A, PF>0.95 |
Output feature & suit battery | WP1800-420400: 42V 40A, suit 10s Li-ion 40~400Ah WP1800-432400, 43.2V 40A, suit 12s LiFePO4 40~400Ah | |
Power efficiency | 92% | |
Charge Curve | pre-charge + C.C. charge + C.V. charge + cut-off | |
Charge Display | Three-color LED indicate charging status | |
Size & Weight | 288x 168 x 89mm/4300g | |
Protections | OCP, OVP, short circuit, battery reverse, waterproof | |
Safety & EMC | CE, FCC | |
Housing & cooling | Aluminum Alloy casting housing, FAN cooling, IP67 class | |
Input & output type | AC plug type: US, EU, PSE, CCC; DC type: Anderson SB-50 | |
Communication port: CAN (More details, click here to download specification, (WP1800-EN.pdf ) | ||
